Creating a OneCX Application

This guide walks you through the process of creating a simple OneCX Application using the OneCX App Generator and integrating it into your local OneCX environment.

Introduction

What is a OneCX Application?

A OneCX Application is a set of microfrontends and services that together provide specific functionality within the OneCX platform. It typically consists of a user interface (a microfrontend) and backend services that support its operations. A OneCX Application is designed to be modular, scalable, and easily integrable with other applications within the OneCX ecosystem.

See also:

A OneCX Application consists typically of the following components.

Application Components

  • onecx-hello-world-ui ⇒ Microfrontend
    The user interface (UI) component that displays the welcome message.

  • onecx-hello-world-bff ⇒ Microservice
    Backend For Frontend (BFF) service that handles any backend logic required by the UI.

  • onecx-hello-world-svc ⇒ Microservice
    Backend Service (SVC): A simple service that could be used to log visits to the application (optional for this basic example).

Prerequisites

Before you begin, ensure you have the following prerequisites in place:

  • A working OneCX Local Environment set up. If you haven’t done this yet, follow the instructions in the OneCX Local Environment Setup.

  • Node.js, npm, nx installed on your development machine.

  • Familiarity with Angular, as the microfrontends in OneCX are typically built using this framework.

  • You need about 1GB of free disk space and it may take a few minutes to download and set up all necessary dependencies.

  • Get and prepare the OneCX App Generator:
    Install it globally or use npx to run it without installation.

    • The onecx-nx-plugins repository needs to be cloned into a folder on the local machine/inside WSL2.

      git clone https://github.com/onecx/onecx-nx-plugins.git

    • Navigate into the cloned repository and install the dependencies:

      cd onecx-nx-plugins
npm install

    • Build the OneCX App Generator:

      npm run build

Create the UI Component

In this tutorial, we will create a simple OneCX application with Angular called "Hello World" that displays a welcome message to users.

Generate UI Component

First, we will generate the onecx-hello-world-ui using the OneCX App Generator.

  1. Open a terminal and navigate to the directory where you want to create your OneCX Application.

  2. Run the OneCX App Generator command:

    Create a new UI component using the ngrx template:
    npx @onecx/create-workspace ngrx onecx-hello-world-ui

  3. Follow the prompts to provide details about your app, such as its name, description, and any specific configurations you want to include.

  4. Once the generation process is complete, navigate into your new onecx-hello-world-ui directory and update dependencies:

    cd onecx-hello-world-ui
npm install

Fixing UI Component

The generated onecx-hello-world-ui component requires a few adjustments to align with our naming conventions and to ensure proper integration with the backend services.

  1. Renaming and fixing OpenAPI file:

    • Navigate to the src/assets/swagger/ folder inside the onecx-hello-world-ui project.

    • Rename the directory swagger to api.

    • Rename the file onecx-hello-world-ui-bff.yaml to openapi-bff.yaml.

    • Open the file and replace all occurrences of onecx-hello-world-ui-bff with onecx-hello-world-bff.

    • Save the changes

    • Navigate back to the root folder of the onecx-hello-world-ui project.

    • Open the file package.json and replace all occurrences of src/assets/swagger/onecx-hello-world-bff.yaml with src/assets/api/openapi-bff.yaml.

    • Save the changes

  2. Generate the API client code based on the updated OpenAPI specification:

    Generate the API client code:
    npm run apigen

  3. Fixing Docker file:

  4. Fixing Proxy configuration:

  5. Fixing the app name throughout the project:

    1. In the Webpack configuration:

      • Open the webpack.config.js file located in the root of the onecx-hello-world-ui project.

      • Locate the name property in the ModuleFederationPlugin configuration.

      • Change the value from onecx-hello-world-ui-app to onecx-hello-world-ui.

      • Save the changes.

    2. In the Typescript configuration:

      • Open the tsconfig.app.json file located in the root of the onecx-hello-world-ui project.

      • Locate the line with .remote-module property within the files section.

      • Change the value from onecx-hello-world-ui-app.remote.module.ts to onecx-hello-world-ui.remote.module.ts.

      • Save the changes.

    3. In the Bootstrap configuration:

      • Open the bootstrap.ts file located in the src of the onecx-hello-world-ui project.

      • Locate the line with import the UI module.

      • Change the value from onecx-hello-world-ui-app.remote.module.ts to onecx-hello-world-ui.remote.module.ts.

      • Save the changes.

    4. In the App module configuration:

      • Open the app.module.ts file located in the src/app of the onecx-hello-world-ui project.

      • Locate the line with imports the PortalCoreModule.

      • Change the value from onecx-hello-world-ui-app to onecx-hello-world-ui.

      • Save the changes.

    5. Change the remote module file name:

      • Rename the file onecx-hello-world-ui-app.remote.module.ts to onecx-hello-world-ui.remote.module.ts in the src/app of the onecx-hello-world-ui project.

  6. Fixing the module name inside the remote module file:

    1. Open the onecx-hello-world-ui.remote.module.ts file located in the src/app of the onecx-hello-world-ui project.

      • Locate the export class declaration.

      • Change the value from OnecxHelloWorldUiModule to OneCXHelloWorldModule.

      • Save the changes.

    2. In the Bootstrap configuration:

      • Open the bootstrap.ts file located in the src of the onecx-hello-world-ui project.

      • Locate the 2 affected lines where the module is referenced.

      • Change the value from OnecxHelloWorldUiModule to OneCXHelloWorldModule.

      • Save the changes.

    3. In the Webpack configuration:

      • Open the webpack.config.js file located in the root of the onecx-hello-world-ui project.

      • Locate the exposed module name

      • Change the value from OnecxHelloWorldUiModule to OneCXHelloWorldModule.

      • Save the changes.

    4. In the values.yaml:

      • Open the values.yaml file located in the helm directory of the onecx-hello-world-ui project.

      • Locate the exposed module name

      • Change the value from OnecxHelloWorldUiModule to OneCXHelloWorldModule.

      • Save the changes.

    5. Change the app title:

      • Open the index.html file located in the src of the onecx-hello-world-ui project.

      • Locate the <title> tag.

      • Change the value from OnecxHelloWorldUi App UI to OneCX Hello World UI.

      • Save the changes.

  7. Fixing the routing path :

    • Open the values.yaml file located in the helm directory of the onecx-hello-world-ui project.

    • Locate the path property under the routing configuration.

    • Change the value from /mfe/onecxHelloWorldUi/ to /mfe/helloworld/.

    • Save the changes.

Your onecx-hello-world-ui component is now set up.

Testing UI Component

After developing your UI component, it’s important to test it locally to ensure everything works as expected before deploying it within your OneCX environment.

Start the UI component locally with:
nx serve onecx-hello-world-ui --proxy-config=proxy.conf.js

Now you can see the UI works with accessing the remoteEntry.js via http://localhost:4200/remoteEntry.js.

or alternatively,

Use the start script and a custom port:
npm run start -- --port=6021 --host 0.0.0.0 --disableHostCheck --publicHost=http://localhost:6021

This will start the UI component on port 6021, and you can access it at http://localhost:6021/remoteEntry.js.

screenshot successful start local mfe
Figure 1. Successfully running UI component on port 6021
